Technical Parameter:

1. Size: 1400*180*980 mm (can be customized)

2. Lane Width: 600 mm (Standard) 900 mm( Handicapped)

3. Arm Material: Acrylic

4. Passing speed: 40 person/min

5. Power supply: 110V/220V 50/60Hz

6. Brushless motor

7. Gate Open Signal: Dry Contact/ Relay

8. Driving Motor: 24V

9. Weight: 50 kg/pcs

10.  Size and material thickness can be customized

11. Casing Material: 304 stainless steel

12. Reliability of the mechanism: 3 million, no-fault

13. LED lights on arms is available

14. LED on the sideboard is optional

15. Swing arm thickness: 10 mm

16. Working Direction: Bidirectional/Single directional

17. Emergency situation: open automatically when the electricity is cut off with a capacitor

18. Humidity: ≤90％

19. Working temperature: -20℃～60℃

20. Communication distance: ≤1200 m

21. Communication interface: RS485

22. Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc

23. Time needed for opening: 0.2 s

24. Working environment: Indoors

25. Application range: Community, Factory, Construction site, School, Place of the resort, etc

We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution.
