Technical Parameter:
1. Size: 1400*280*980 mm (can be customized)
2. Lane width: 550 mm (can be customized)
3. Passing speed: 35 person/min
4. Power supply: 110V/220V 50/60Hz
5. Weight: 35 kg
6. Input: Dry Contact/Relay
7. Brushless Motor Mechanism
8. Casing Material: 304 stainless steel
9. Reliability of the mechanism: 3 million, no-fault
10. Operation way: semi-automatic
11. Solenoid valve: DC24V ±5%
12. Arm Length: 510 mm
13. Direction of rotation: Bidirectional/Single directional
14. Emergency: Arm drops automatically when the electricity is cut off.
15. Operational voltage: DC 24V ±5%
16. Voltage of indicator light: DC12V ±5%(standard)
17. Working temperature: -30℃~60℃
18. Humidity: 5%~90%
19. Waterproof: IP43
20. Automatic self-check once power on
21. Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
21. Time needed for opening: 0.2 s
22. Working environment: Indoor or outdoor
23. Application range: Community, Factory, Construction site, School, Place of the resort, etc
We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution.
