Technical Parameter:

1. Size:1500*1500*2310 mm (can be customized)

2. Lane Width: 650 mm (can be customized)

3. Passing speed: 30 person/min

4. Power supply: 110V/220V 50/60Hz

5. Solenoid: DC24V

6. Gate Open Input: Dry Contact/Relay

7. Logic Voltage: DC24V

8. Casing Material: 304 stainless steel

9. Reliability of the mechanism: 5 million, no-fault

10.  Mechanism comes with hydraulic damper for shock-absorbing

11. Drive: Semi-automatic Operated

12. Arm length: 640 mm

13. Direction of rotation: Bidirectional/Single directional

14. Emergency situation: In the event of an emergency or isolation of the power supply the Rotating Door can be configured to Fail-Safe i.e. rotates freely or Fail-Lock

15. Humidity: ≤95％

16. Working temperature: -25℃～60℃

17. Optional Feature: IC/ID reader, Barcode Reader, other R/W equipment, UPS, Infrared detector

18. Communication distance: ≤1200 m

19. Communication interface: RS485

20. Size can be customized

21. Time needed for opening: 0.2 s adjustable

22. Working environment: Indoors or outdoors(outdoor is optional)

23. Application range: Community, Factory, Construction site, School, Place of the resort, etc

We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution.
